Streamline workflow design

The Workflow Designer application is the central hub within the dataminer.MediaOps solution for defining technical workflows. Designed for media engineers, this application empowers users to create and manage workflows for both ad-hoc and scheduled operations.

Key actions within the app include adding nodes to a workflow, defining booking behavior, creating connections between nodes, describing workflow execution behavior, and specifying monitoring settings.

Node management

Users can easily add nodes to workflows, representing the different actors contributing to workflow execution. Four node types are available: Source, Destination, Resource, and Resource Pool. Each node offers configuration options such as optional aliases and inclusion in booking, providing flexibility and customization in workflow design.

Connection setup

The Workflow Designer allows users to create connections between nodes to facilitate workflow execution. Users can define the type of connection (e.g., Level-based), subtype (e.g., All, Predefined subset, Custom subset), and execution order. This feature enables users to establish network connectivity between nodes based on predefined criteria, optimizing workflow efficiency.

Workflow execution behaviour

Users can describe what should happen during workflow execution by providing automation scripts. The Workflow Execution Script outlines the overall execution logic, triggered by the system during workflow execution. Additionally, the Connection Execution Script, an optional property of all connections, allows users to define specific actions when connecting sources to destinations. These scripts provide users with granular control over workflow behavior, enhancing customization and adaptability.
